but then you will most likely need an additional balancer cable harness or more chargers to charge/balance each cell individually if you want speedy charging), so for efficiency & simplicity we base our 12s power on the use of 2x 6s cells as generally speaking there are many good priced nice performing chargers put there which also have the ability to balance your cells to prevent failiure of the cell, already on the market are capable of charging up to 2x 6 cells at any 1 time, So as you now know, to achieve 12s power requires a minimum of 2x 6s Batteries (it could be more cells if you were custom making your battery or if you were achieving 12s from 6x 2s, 4x 3s or 3x 4s cells as they can all be harnessed together to make 12s power.
Do not push more power than 12s into the VESC6. Using a XT90 Battery harness cable kit to connect 2x 6s batteries together will double the battery power resulting with a 12s Battery WITHOUT Any soldering or Welding!!
When 12s power is pumped into the VESC6 you will be able to experience the kind of riding performance everybody is talking about. :-)ġ2s power is the perfect amount of power to be pushed through any of the TRAMPA Electronic products (12s should only be applied when using the very special TRAMPA VESC6 speed controller). The charger comes with a UK or EURO Plug for wall plug in connection, XT90 Jack leads & 2x 7 pin adaptor plates which allow balancer cable connections from 2x batteries from 1s to 6s using JST Connectors. As the Graupner is our suggested charger for the Zippy cells this charger is somehow incorporated into the design of our Battery Boxes so using this charger is nice easy to connect, it is reasonably fast to charge whilst it balances (looking after) your cells at the same time and you dont need to remove anything in order to charge as the cells are all snugly secured away in one of the amazing Carbon fiber boxes, which as it so happens have been designed special for this style of charger & easy charging. The Ultramat 18 charger is used by the TRAMPA team for charging all of our decks that use Zippy Cells for power. % total / cell battery capacity.This GRAUPNER ULTRAMAT Charger is capable of Charging & Balancing all cells up to 12s in power. BATTERY GUARD SPEC MODE TYPE SPEC MEMO INPUT CELL NiCd /NiMH MIN : 4 CELL MAX : 7 CELL LiPo / LiFe / LiIon MIN : 2 CELL MAX : 7 CELL Display Type Segment LCD 71 dot Buzzer magnetic Beep Control INPUT Tact switches 3 buttons Case Type Plastic case Total V Ni‐type / Li‐type 1~7CELL Voltage Li‐type only Max Highest cell voltage Display Min Lowest cell voltage Li‐type only Max‐Min Voltage gap between highest cell volt and Lowest cell volt. Displays : Battery cell voltages, Total voltages, Lowest cell voltage, Highest cell voltae, Voltage gap between highest cell voltage and lowest cell voltage, Remaining vattery capacity (%) / BAR Cell Number : NiCd/MH(4 ~ 7CELL), Li_type (2 ~ 7CELL) 3.
Battery Type : Nicd/NiMH, LiPo, LiFe, LiIon 2. BATTERY GUARD PRODUCT STUCTURE Ni- type BATTERY INPUT Li-BATTERY INPUT (CELL CONNECTOR) TYPE CELL MODE ‐ BATTERY GUARD 1.
